Location | Tel Aviv, Israel |
Investor | Tel Aviv Metropolitan Area Mass Transit |
Client | YENON RESEARCH & DESIGN Ltd., Israel |
Designer | PONTING - PIPENBAHER CONSULTING ENGINEERS |
Services | Conceptual / Preliminary design |
Length | 230.0 m |
Span arrangement | 95.0 + 135.0 = 230.0 m |
Total width | 12.4 - 13.0 m |
Total pylon height | 79.0 m |
Type of foundations | Deep on bored RC piles, diameter 1.20 m |
Superstructure | Composite U shape girder |
Construction technology | Balanced cantilever method |
